WE MAKE IT HAPPEN / 忠山機械,完美實現。

JS-10 Servo Type + Touch Panel

JS-10 Servo Type + Touch Panel

Automatic Quantitative Granule Filling & Packaging Machine

Machine Features

  • Servo Motor control for ease & efficient packaging works.
  • 90% setting are through touch panel for user friendly operation.
  • Touch panel enable to set up: cutting mode (eye mark cutting or length cutting), packing speed, counter, quantity warning, sealing temperature, packaging data memory…etc.
  • Auto detect function with quick trouble shooting display.
  • Multiple memory programs to record packaging data.
  • All component in direct contact with product are made with SS304 or food sanitary standard.
  • Individual temperature controller with PID function for each sealing part.
  • Bag width is adjustable by changing bag former guide.
  • Bag length is setting through the panel directly.
  • Machine build by iron cast with stainless steel frame.


Optional Device

Date coder, level indicator, input/output product conveyor, nitrogen air connector, height adjustable dish and other required device upon request.


Applicable Products

Various powder & granule, such as: tea, 3 in 1 coffee, coffee bean, milk tea powder, herbal tea, peanuts, chocolate ball, crackers, pet food…etc.


Applicable Film

Heat seal suitable filter paper, double layer heat sealable laminated film, such as: PET+LLDPE, PET+MPET+CPP, PET+PE+AL+LLDPE, Nylon+LLDPE…etc.


Sealing Type

JS-10 Servo Type + Touch Panel

Elementor Pro

View Details!
Sealing Style

3 sides, 4 side or pillow type packaging(one option)


Servo Motor


220V, 50 or 60 Hz, single phase(upon request)

Film Width

60-160 or 80-220mm

Bag Length


Filling Weight

1-10g / 10-30g / 30-60g / 60-100g (varies with product density)

Packaging Speed

About 20-90 bags /min

Machine Dimension

75 x 60 x 175cm(L x W x H)

Net Weight



  • Other packaging sizes available upon request.
  • Filling rang e& Packaging speed will be differ from product density, weight & film.
