JS-16A PLC Control + Servo Type + Pneumatic Sealing

JS-16A PLC Control + Servo Type + Pneumatic Sealing

Automatic Auger Type Powder Filling & Packaging Machine

Machine Features:

  • PLC Control + Servo Motor for ease operation.
  • Touch Panel for easy usage to set up: bag length、filling weight、speed、sealing temp、eye mark、counter、QTY warning、memory record…etc.
  • Auger screw is one-piece formed and which is manufactured of stainless steel 304, comes with food sanitary standards.
  • Suitable for light density、hard flowing related powder.
  • Filling Weight adjustable through panel directly.
  • Pneumatic sealing type for nice sealing packaging performance.
  • Enable to set up required sealing & cutting time.
  • Film tension control for stable film filling & pulling.
  • Sealing and cutting operations are air cylinder activated for fast, highly efficient operations.
  • Multiple memory programs to record/read different packaging data.
  • Auto eye mark tracing in a short time.
  • Auto warning display for quick trouble shooting.
  • PID function temp. controller for each sealing part with stable sealing performance.


Optional Device:

Date coder, product input / output conveyor, nitrogen air connector, quantity warning,…etc., and other required device upon request.


Applicable Products:

Various powder, such as: seasoning powder, milk powder, flour powder, rice powder …etc.


Applicable Film:

Double layer heat seal suitable laminated film, such as: PET+LLDPE, PET+MPET+CPP, PET+PE+AL+LLDPE, Nylon+LLDPE…etc.


Sealing Type:

JS-16A PLC Control + Servo Type + Pneumatic Sealing

Elementor Pro

View Details!
Sealing Style

3 sides, 4 side or pillow type packaging(one option)


PLC Control + Servo Motor


220V, 50 or 60 Hz, 3 phase(upon request)

Film Width

60-160 or 80-220mm

Bag Length


Filling Weight

10-30g / 30-50g / 50-100g (varies with product density)

Packaging Speed

About 20-70 bags/min

Machine Dimension

174 x 132 x 185cm(L x W x H)

Machine Weight



  • Other packaging sizes available upon request.
  • Filling range& Packaging speed will be differ from product density, weight & film.
  • 6kg/cm2 compressed air with dry air filtering system self-prepared is required.
