JS-14 PLC Control+Servo Motor+Pneumatic Seal

JS-14 PLC Control + Servo Motor + Pneumatic Seal

Automatic Quantitative Liquid Filling & Packaging Machine

Machine Features:

  • PLC Control + Servo Motor for ease & efficient packaging works.
  • Pneumatic sealing construction with SMC cylinder drive for stable sealing performance.
  • Sealing and cutting operations are air cylinder activated for fast, highly efficient operations.
  • Piston injection with servo motor & screw control filling for accurate filling volume.
  • Filling control with SMC cylinder drive ensures clean sealing performance.
  • Enable to set up sealing & cutting time separately.
  • Patent design anti-drop filling function ensure clean sealing performance.
  • 90% setting are through touch panel for user friendly operation.
  • Touch panel enable to set up: filling volume, bag length, eye mark cutting, speed, counter, sealing temperature, packaging data memory…etc.
  • Film tension control for stable film filling process.
  • Auto detect function with quick trouble shooting display.
  • Safety sealing line at side to prevent leakage situation with tight sealing performance.
  • Individual temperature controller with PID function for each sealing part.
  • All component in direct contact with product are made with stainless steel or food sanitary standard.



Applicable Products:

  • Food related, such as: soy bean milk, oil, tomato ketchup, soy sauce, chicken essence, paste, chili sauce, honey, juice,…etc.
  • Cosmetic related, such as: lotion, cream, shampoo, conditioner, foundation…etc.
  • Other items, such as: grease oil, biotechnology product, and other liquid & paste products.



Applicable Film:

Double layer heat sealable laminated film, such as: PET+LLDPE, PET+MPET+CPP, PET+PE+AL+LLDPE, NYLON+LLDPE…etc.



Sealing Style:



JS-14 PLC Control+Servo Motor+Pneumatic Seal

Elementor Pro

View Details!
Sealing Style

Pillow type packaging

Power

220V, 50 or 60 Hz, single phase(upon request)

Film Width

240-480mm

Bag Length

200-400mm

Filling Range

100-500cc / 500-1000cc / 1000-2000cc(varies with product density)

Packaging Speed

About 10-30 bags/min

Machine Dimension

280x 120 x 190cm(L x W x H)

Net Weight

880kg

Note

  • Other packaging sizes available upon request.
  • Filling range& Packaging speed will be differ from product density, weight & film.
  • 6kg/cm2 compressed air with dry air filtering system self-prepared is required.
