JS-68 Double Wrapped Packaging –Tea bag with String & Tag (PLC Control + Touch Panel)

JS-68 PLC Control + Touch Panel

Double Wrapped Packaging –Tea bag with String & Tag

Automatic Quantitative Double Wrapped Filling & Packaging Machine

Machine Features:

  • PLC Control + Touch Panel for ease operation.
  • Fully automatic packaging process from inner to outer bag.
  • Inner bag to outer bag with cylinder & sensor control to ensure completed packaging.
  • Inner bag auto attach with string& tag, without staple.
  • Extension area in the bottom of bag to extend tea leaf completely.
  • Touch panel for multiple function setting, user friendly operation.
  • Auto warning display for quick trouble shooting display.
  • Volumetric Filling method with metering dish & cups.
  • Enable to equip vibration & agitator to enhance product filling fluidness according to request.
  • All component in direct contact with product are made with SS304 or food sanitary standard.
  • PID function temp. Controller for each sealing part with stable sealing performance.
  • PLC control photocell device for outer bag, auto tracing eye mark in a short time.
  • Auto detection function on: inner material, outer material, string attaching, tag delivery, hopper level, inner bag filling to outer bag.
  • Product output conveyor attached with machine.


Optional Device:

Date coder, product input conveyor, nitrogen filling connector…etc., or other required device upon request.


Applicable Products:

Powder related products, such as: coffee powder, tea, herbs, ginseng …etc.


Applicable Film:

  • Inner bag: Heat seal suitable filter paper, such as: cotton filter paper.
  • Outer bag: Double layer heat sealable laminated film, such as: PET+LLDPE, PET+MPET+CPP, PET+PE+AL+LLDPE, Nylon+LLDPE…etc.


Sealing Type:

JS-68 Double Wrapped Packaging–Tea bag with String & Tag

Elementor Pro

View Details!
Sealing Style

3 sides sealing


1/4 HP


220V, 50 or 60 Hz, single phase(upon request)

Inner Bag Size

(W)70 x (L)59mm

Outer Bag Size

(W)100 x (L)80mm

Filling Weight

1-5g (varies with product density)

Packaging Speed

About 30-45 bags/min

Machine Dimension

155x 130 x 235cm(L x W x H)

Net Weight



  • Other packaging sizes available upon request.
  • Filling weight& Packaging speed will be differ from product density, weight & film.
  • 6kg/cm2 compressed air with dry air filtering system self-prepared is required.
